2027 Arctic Cat Jag 400

Name: 2027 Arctic Cat Jag 400
Brand: Arctic Cat
Availability: OutOfStock

Call Email

Call for Price

Contact Us Get Approved Value a Trade Get Directions Get Directions Print

Overview

Jag

Trail Performance, Reimagined

The Jag is back — bringing its race-inspired heritage to the trail in a way few expect. Compact and approachable, the Jag lineup is built to surprise, delivering sharp handling and confident cornering that punches well above its weight.

Jag 400

The Trail Sleeper

397cc C-TEC2 Single Cylinder EFI Engine
AMS™ 37 Front Suspension
Hydraulic Twin Tube Shocks
14” x 121” x 1” Hacksaw Track
Electric Start
High Windshield

Specifications

Model

Jag

Category Name

Snowmobiles

Year

2027

Sale Type

New

Manufacturer

Arctic Cat

engine

Cooling

Liquid

Exhaust

APV with Tuned Pipe, Pipe Sensor, Manifold & Stainless Steel Muffler

Ignition

Digitally Controlled CDI

Cylinders

1

Engine Type

400, 2-Stroke

Lubrication

Electronic Injection

Displacement

397cc

Bore X Stroke

85 x 70 mm

Fuel Capacity

11.7 gal

Fuel Delivery

Electronic Fuel Injected (EFI)

Minimum Octane

91

Oil System Capacity

3.25 qt

Engine Stator Output

270W @ 3000 RPM

Coolant System Capacity

4.6 qt

powertrain

Brakes

Stealth Hydraulic Master Cylinder

Gearing

19/50

Reverse

Push-Button Engine

Chain Pitch

90

Drive Clutch

CVTech Trailbloc

Drive System

Arctic Drive System

Driven Clutch

CVTech Trailbloc

Clutch Calibration

0-5,000 ft

Track Drive Sprocket

9 tooth, 2.52 pitch, involute

suspension

Sway Bar

Standard

Ski Shocks

Hydraulic Twin Tube

Rear Travel

10.7

Front Travel

7.2 in

Rear Suspension

Slide-rail, dual shock and adjustable torsion springs

Front Suspension

Arctic Mountain Suspension (AMS)

Rear Track Shock

Hydraulic Twin Tube

Front Track Shock

Hydraulic Twin Tube

dimension

Lug

1.00 in

Pitch

2.86 in

Ski Stance

37.5-38.5 in - Adjustable

Track Type

Hacksaw

Runner Type

Single runner w/ carbide

Track Width

14 in

Track Length

121 in

Ski Type/Width

Trail - 6 in

Overall Chassis Width

44-45 in

Overall Chassis Height

51 in

Overall Chassis Length

115 in

instrumentation

Oil

Indicator Light

Fuel

Digital

Hours

Digital

Coolant

Indicator Light

Odometer

Digital

Tachometer

Digital

Speedometer

Digital

Type Of Gauge

Standard

features

Color

Black

Seating

Mid-Size

Starter

Turnkey Electric Start

Lighting

Halogen 1-Bulb

Handlebars

Hooked

Windshield

15.5 in High

Heat Exchanger

Front/Long Tunnel

Standard Accessories

Hand & Thumb Warmers, Standard Brake Disc, Standard Steering, Tether Switch

main features

Powerful and Responsive

400 SERIES EFI ENGINE

With an industry-first design that’s compact and lightweight, this EFI engine brings 65-hp and 397cc performance to every ride, all while remaining under 50 lbs. A 3-stage exhaust valve system takes this power to the next level, delivering improved throttle response and better overall engine performance. As a liquid cooled engine, a counter balance shaft eliminates most engine vibration. The result—a lightweight-but-mighty power source that fuels a ride like no other.

Eliminates Bumpy Rides

SLIDE-RAIL REAR SUSPENSION

This responsive rear suspension uses a full 13.5 inches of travel to absorb any bumps on the trail. With support like this, every ride will be so stable and smooth, you won't even notice the rough snow.

Agile Control

MID-SIZED CHASSIS

There's nothing better than a snowmobile that's easy to handle. With its lightweight, mid-sized chassis, the Jag 400 gives you more control over your ride as you explore the trails.
